H_4XHDMI INPUT CARD | Carte d'Entrée Quadruple HDMI Novastar H | Multi-Source 4K

The Novastar H_4XHDMI Input Card is a high-density expansion module engineered for the Novastar H-Series Video Wall Processors, such as the H2, H5, and H15. This professional-grade card features four independent HDMI input ports, allowing for the simultaneous integration of multiple high-resolution video sources. Designed for demanding LED display ecosystems, it provides the bandwidth necessary to handle complex pixel maps and high-bit-depth signals with ease. Whether you are managing multiple 1080p feeds or a combined 4K/8K mosaic, this card ensures that your video data is processed with zero-frame latency, maintaining the integrity of the refresh rate and color accuracy across the entire screen. Its hot-swappable architecture allows for seamless system upgrades and maintenance without powering down the main chassis, making it a critical component for mission-critical operations and large-scale visual installations.

Professional Processing for High-End LED Video Walls

As a key component of the Novastar H-Series ecosystem, the H_4XHDMI Input Card is designed to maintain the highest levels of signal integrity. Unlike standard consumer hardware, this module is built to interface directly with high-performance LED controllers, ensuring that the grayscale, contrast ratio, and color gamut are preserved from source to screen. Utilizing advanced FPGA processing, the card supports high refresh rates, which is crucial for flicker-free performance in broadcast and XR environments.

Advanced Signal Handling and Reliability

• High Density Connectivity: Four HDMI ports on a single card maximize the slot efficiency of your H-Series chassis, allowing for more inputs in a smaller footprint.
• Sync and Latence Control: Optimized for low-latency processing, ensuring that video and audio remain perfectly synchronized, even when using SMD or GOB LED modules with high scan rates.
• EDID Management: Features customizable EDID settings, allowing the card to communicate flawlessly with diverse sources to ensure the optimal resolution and frame rate output.
• Hardware Stability: Built with industrial-grade components to thrive in 24/7 operational environments like command centers.

Versatile Deployment Scenarios

The H_4XHDMI Input Card is a versatile solution for numerous professional AV environments:

• Broadcast Control Rooms: Ideal for monitoring four different camera feeds or playback sources on a single large-format LED backdrop.
• Live Events & Concerts: Allows VJs and video engineers to quickly switch between multiple media servers or live-feed laptops with minimal transition time.
• Command & Control Centers: Perfect for displaying multiple data streams, such as CCTV feeds and real-time analytics, across a high-resolution LED video wall.
• Corporate Lobby Displays: Enables the blending of various content sources, from high-definition branding videos to live news tickers, using the H-Series multi-windowing capabilities.
• Digital Signage: Provides the input density required for large-scale retail installations with complex multi-screen layouts.

Technical Implementation and Optimization

To maximize the performance of your H_4XHDMI Input Card, consider the following technical recommendations:

• Cable Quality: Always use high-quality, shielded HDMI cables to maintain signal stability, especially when pushing 4K resolutions or high refresh rate content.
• Slot Placement: Ensure the H-Series chassis firmware is up to date before installation. This facilitates immediate recognition of the hot-swappable module and ensures compatibility with the latest H-Smart control software.
• Resolution Matching: For the best visual results, match the input resolution of your source to the native pixel pitch and resolution of your LED wall to minimize scaling artifacts.
• Thermal Management: Maintain a clean, dust-free environment for the chassis. Proper airflow is essential to prevent thermal throttling of the high-speed HDMI interface chips.
