H_1XHDMI2.0+1XDP1.2 CARD | Carte d'Entrée Dual Mixte 4K Novastar H | HDMI/DP

The Novastar H_1XHDMI2.0+1XDP1.2 Mixed Input Card is a high-performance modular component designed specifically for the H Series Video Wall Processors. Engineered for high-definition video processing, this card provides a seamless interface for 4K video sources, ensuring that your LED display maintains exceptional signal integrity. By supporting both HDMI 2.0 and DisplayPort 1.2 standards, it allows for a diverse range of input possibilities, catering to modern high-end video production environments. As a crucial element in the H Series ecosystem, this card enables true 4K@60Hz resolution, providing the bandwidth necessary for high-refresh-rate applications. Whether you are managing a fine-pitch LED display with high contrast requirements or a large-scale event screen, this input card ensures that every pixel is delivered with precision and low latency. It is an essential upgrade for professionals seeking reliability and versatility in their signal distribution infrastructure.

Deep Integration and Processing Excellence

As experts at Pixelight, we understand that the quality of an LED display starts long before the light leaves the SMD or GOB pixels. The H_1XHDMI2.0+1XDP1.2 Input Card serves as the critical bridge between your source and the LED controller. Supporting resolutions up to 3840×2160@60Hz, it preserves the high refresh rate and color depth required for professional broadcasting and high-end corporate installations.

Advanced Hardware Architecture

• Dual Input Versatility: Features one HDMI 2.0 and one DP 1.2 port, facilitating high-bandwidth data transmission without compression.
• Seamless Integration: Designed for the H Series Video Wall Processor, enabling high-performance hardware-based processing for reduced latency compared to software solutions.
• HDR Support: Ensures that the high contrast ratio and wide color gamut of your LED panels are fully utilized, delivering deep blacks and vivid highlights.
• HDCP Compliance: Full support for HDCP 2.2 ensures compatibility with protected high-definition content, vital for commercial and retail environments.

By utilizing this card, integrators can ensure that the signal chain remains robust, avoiding common artifacts such as tearing or frame drops that can occur with lower-tier input modules.

Versatile Deployment Scenarios

The Novastar H_1XHDMI2.0+1XDP1.2 Mixed Input Card is a versatile solution designed for demanding environments where signal quality is non-negotiable:

• Command and Control Rooms: Ideal for displaying high-resolution mapping and data visualizations on fine-pitch GOB displays with no latency.
• Broadcast Studios: Perfect for feeding ultra-high-definition backgrounds where high refresh rates (3840Hz+) are required to avoid moiré and flickering on camera.
• Corporate Auditoriums: Provides the flexibility to switch between DP-based workstations and HDMI-based presentation laptops seamlessly.
• Fixed Commercial Installations: reliable 24/7 operation for high-end retail signage where the contrast ratio and 4K clarity define the brand experience.
• Live Events: Robust input stage for large-format rental LED screens at concerts and sporting events.

Technical Optimization for 4K LED Systems

To maximize the performance of your H Series processor equipped with the Mixed Input Card, our technical team recommends the following:

• Cable Integrity: Use certified Premium High Speed HDMI 2.0 or DP 1.2 cables. For lengths exceeding 5 meters, consider active optical cables (AOC) to maintain signal stability and avoid "sparkle" artifacts on the LED wall.
• EDID Management: Configure the EDID (Extended Display Identification Data) on the input card to match the native resolution and refresh rate of your LED configuration for optimal pixel-to-pixel mapping.
• Power Cycling: Ensure the H Series chassis is powered down before inserting or removing input modules to protect the sensitive FPGA circuitry.
• Firmware Sync: Always synchronize the firmware version of your input cards with the H Series motherboard using NovaLCT or the web interface to ensure full feature compatibility.
