H_2XRJ45+1XHDMI1.3 PREVIEW CARD | Carte de Prévisualisation HDMI/RJ45 Novastar H

The H_2XRJ45+1XHDMI1.3 PREVIEW CARD is a high-performance monitoring module specifically engineered for the Novastar H-Series modular LED video wall processors. This essential component provides a dedicated HDMI 1.3 output, enabling real-time monitoring of input sources and program outputs on a standard control room display. By facilitating a live preview of multi-layer compositions and complex PIP/POP arrangements, it ensures that technicians can verify signal integrity and visual transitions before they are pushed to the main LED video wall. Additionally, the card features dual RJ45 ports for robust control network communication, ensuring seamless integration within professional AV infrastructures. Designed for mission-critical reliability, this hot-swappable module allows for rapid hardware scaling and maintenance without power-cycling the main chassis, making it a cornerstone for professional broadcast and live event production workflows.

Professional Monitoring Reliability in H-Series Ecosystems

As technical experts at Pixelight, we recognize that signal validation is paramount in large-scale LED deployments. The H_PREVIEW CARD leverages high-bandwidth processing to deliver a low-latency HDMI 1.3 signal, crucial for maintaining synchronization between the operator's monitor and the final output on the LED display. Unlike standard output cards, this module is optimized for the H-Series backplane architecture, ensuring that the preview feed accurately reflects the processing applied to pixels, regardless of whether you are using high-density SMD or high-contrast GOB LED modules.

Control and Stability

The integration of dual RJ45 ports provides dedicated bandwidth for control plane data, isolating service communication from the video stream to prevent jitter or latency spikes. Key technical advantages include:

• Low Latency Processing: Minimizes the delay between source input and preview output, essential for real-time adjustments.
• Modular Hot-Swap Design: Allows for immediate replacement or upgrades in 24/7 environments, maintaining the high uptime required for control rooms.
• Signal Integrity: Provides a stable Full HD monitoring output, allowing for detailed inspection of refresh rate performance and color accuracy before the signal reaches the receiving cards.

Deployment Scenarios for the H-Series Preview Card

The H_2XRJ45+1XHDMI1.3 PREVIEW CARD is an indispensable tool across various high-stakes AV environments:

• Live Broadcast and Events: Enables directors to preview complex transitions and multi-layer graphics (PIP/POP) before going live, preventing visual errors on the main stage.
• Command and Control Rooms: Provides operators with a continuous "at-a-glance" view of the entire video wall layout on a local desktop monitor, ensuring 24/7 surveillance of operational data.
• Corporate Showrooms: Simplifies the management of high-resolution content, allowing for seamless switching between different presentation sources with total confidence.
• Retail Hubs: Facilitates remote maintenance and content verification, ensuring that the brightness and visual quality across the LED network remain consistent with brand standards.

Technical Configuration and Maintenance

To maximize the performance of your Novastar H_PREVIEW CARD, our technical team recommends the following best practices:

• Viewing Distance & Monitoring: Use a high-quality Full HD monitor with a high contrast ratio to accurately judge the content scaling and color balance before it is displayed on the fine-pitch LED wall.
• Controller Settings: Ensure the H-Series chassis firmware is up to date to support the latest OSD (On-Screen Display) features on the preview output, which can display source names and status indicators.
• Power & Scaling: Since the card is hot-swappable, ensure the locking mechanisms are fully engaged to prevent signal loss. The HDMI output supports standard scaling, making it compatible with most professional multiviewers.
• Maintenance: Periodically check the RJ45 connections for network stability to ensure consistent communication with the NovaLCT or V-Can software interfaces.
