SHAPE 2.6 (500 x 1000)
Discounted price for professionals — Free B2B quote within 24h
Category: LED Screen Indoor
Pitch : 2.6 mm
Product images
Description
SHAPE 2.6 — indoor LED display
The Pixelight SHAPE 2.6 is an indoor LED panel with a 2,60 mm pixel pitch in a 500 x 1000 mm (5 cabinet sizes) format. Available in five cabinet sizes, it composes surfaces that follow existing structures: extra-wide ribbons, columns, totems and furniture cladding.
The 2.6 mm pitch balances viewing comfort and cost on large indoor surfaces. At just 48 mm thick it is one of the most discreet solutions on the market — decisive when recess depth is constrained. For the reseller, it is the most versatile panel in the SHAPE range.
Key specifications
Pixel pitch: 2,60 mm
Cabinet: 500 x 1000 mm (5 cabinet sizes)
Refresh rate: 3840 Hz
Maintenance: front access
Application: indoor
Technical Expertise
SHAPE 2.6 — technical analysis
The SHAPE 2.6 is an indoor LED panel with a 2,60 mm pitch in a 500 x 1000 mm (5 cabinet sizes) format. Available in five cabinet sizes, it composes surfaces that follow existing structures: extra-wide ribbons, columns, totems and furniture cladding.
The 2.6 mm pitch balances viewing comfort and cost on large indoor surfaces. At just 48 mm thick it is one of the most discreet solutions on the market — decisive when recess depth is constrained. For the reseller, it is the most versatile panel in the SHAPE range.
To settle at project stage: the exact layout of the surface (cabinet format drives the number of visible joints), the available recess depth, and ventilation behind the structure. Comfortable viewing distance starts at 3 m.
Use Cases
- Large indoor surfaces — video walls in lobbies, showrooms and auditoriums.
- Columns and totems — vertical assembly from the narrow cabinets.
- Extra-wide ribbons — continuous lines several metres long.
- Furniture cladding — counters, reception desks, podiums.
- Constrained integration — 48 mm depth for shallow recesses.
Technical Tips
- Viewing distance — comfortable from 3 m; closer than that, move up one step in the range.
- Layout — the five cabinet sizes allow the surface to be adjusted precisely; settle the format mix before ordering.
- Video capture — 3840 Hz removes scan lines; align the controller with the production before the first shoot.
- Brightness — indoors, the level agreed at commissioning takes precedence over the nominal figure; record it for later interventions.
- Maintenance — front access: plan the clearance in front of the panel, not behind it.
Technical Specifications
| Specification | Value |
|---|---|
| Pitch | 2.6 mm |
| Brightness | 800 nits |
| Refresh Rate | 3840 Hz |
| Dimensions (W×H×D) | 500×1000×? mm |
| LED Lifespan | Env. 100 000 heures |
| Color Temperature | 6500k |
| Operating Temperature | -10°C-+50°C |
Frequently Asked Questions
À quelle distance peut-on regarder un écran LED pitch 2.6mm ?
La distance de recul idéale pour un pitch de 2.6mm est d'environ 2.5 à 3 mètres. À cette distance, l'œil humain ne distingue plus les pixels individuels, offrant une image parfaitement nette et homogène.
Quels sont les avantages d'un écran LED intérieur ?
Contrairement aux téléviseurs classiques, les écrans LED indoor offrent une modularité sans bordures (bezel-less) et une luminosité supérieure. Ils garantissent une visibilité optimale même sous un éclairage artificiel intense.
Comment installer un écran LED géant INSTORE 2.6 ?
Le système INSTORE 2.6 permet une installation murale fixe, suspendue ou sur structure autoportée. La maintenance peut s'effectuer par l'avant (front access) pour faciliter l'entretien dans les espaces restreints.
Quelle est la durée de vie d'un écran LED professionnel ?
Un écran LED professionnel comme l'INSTORE 2.6 est conçu pour fonctionner environ 100 000 heures. Cela représente plus de 20 ans à raison de 12 heures d'utilisation par jour (environ 11 ans en fonctionnement continu 24 h/24) en conditions normales d'exploitation.
Quel prix pour un écran LED pitch 2.6mm ?
Le prix dépend de la surface totale en m², du type de structure et de l'électronique de contrôle choisie. Contactez PIXELIGHT pour un devis sur mesure incluant l'installation et la configuration.
