MX_4X10G_FIBER OUTPUT CARD | Carte de Sortie Fibre Quadruple 10G Novastar | Haute Densité

The MX_4X10G_FIBER OUTPUT CARD is a professional-grade high-density expansion module designed for Novastar's modular ecosystem. Engineered for mission-critical LED display projects, this card features four independent 10G SFP+ optical ports, enabling seamless signal distribution over vast distances without the signal degradation typical of copper cabling. By integrating four 10Gbps pipelines into a single slot, it significantly expands the pixel capacity of your controller while providing the necessary bandwidth for high-resolution setups, including 4K and 8K workflows. Whether you are managing complex stage designs or large-scale fixed installations, this card ensures ultra-low latency and electromagnetic interference immunity, maintaining the pristine quality of your visual content from the processor to the receiving cards.

Advanced Signal Integrity and Throughput

In the realm of high-end LED integration, bandwidth management is paramount. The MX_4X10G_FIBER OUTPUT CARD leverages 10 Gigabit Ethernet architecture to handle the massive data rates required by modern SMD and GOB displays. Unlike traditional RJ45 outputs, these fiber ports support higher refresh rates and deeper color depths (10-bit/12-bit) by eliminating the bottleneck of copper-based transmission.

Reliability and Redundancy

• Optical Isolation: Fiber optics provide total immunity to EMI and RFI, which is essential in environments with heavy power cabling or industrial equipment.
• Hot-Swappable Design: Part of the MX series, this card can be replaced or added without powering down the chassis, ensuring zero downtime for critical broadcast or live event scenarios.
• High-Density Architecture: By providing four 10G ports per card, engineers can maximize the slot efficiency of their Novastar Pro chassis, allowing for complex redundancy loops (Primary and Backup) across independent fiber runs.

This technical flexibility allows for the driving of narrow pixel pitch (NPP) displays where contrast ratios and grayscale precision depend on stable, high-speed data delivery.

Versatile Deployment Scenarios

The MX_4X10G_FIBER OUTPUT CARD is the backbone for sophisticated LED architectures across various sectors:

• Live Concerts and Touring: Allows the control room to be positioned hundreds of meters away from the stage LED walls, providing a clean signal for high-brightness SMD outdoor screens.
• Control Rooms and NOCs: Supports 24/7 operation for ultra-fine pitch GOB displays, where signal stability and redundancy are non-negotiable for monitoring critical data.
• Retail and Corporate Hubs: Facilitates large-scale digital signage across multiple floors or wings of a building from a centralized modular processor.
• Virtual Production and Studios: Provides the necessary bandwidth for high-frame-rate content and low-latency synchronization required for XR environments.

Technical Optimization and Installation Tips

To maximize the performance of your MX_4X10G_FIBER OUTPUT CARD, consider the following technical best practices:

• SFP+ Selection: Always use high-quality SFP+ modules compatible with your fiber type (Single-mode for long-range over 10km, Multi-mode for short-range up to 300m) to ensure a stable link.
• Viewing Distance and Resolution: When calculating bandwidth, account for the pixel pitch and total resolution. High-density cards like this are ideal when the controller is located far from the screen to maintain a clean aesthetic at the viewing angle.
• Maintenance: Use optical fiber cleaning kits regularly. Even microscopic dust on the SFP+ interface can cause frame drops or sync issues in high refresh rate configurations.
• Controller Settings: Ensure your Novastar software is updated to recognize the MX-series modular architecture for proper port mapping and redundancy configuration.
