CRYSTAL P2.6 / 5.2 - HB - Dalle LED Semi transparente

CRYSTAL P2.6 / 5.2 HB — Semi-Transparent LED Panel

The Pixelight CRYSTAL P2.6 / 5.2 HB is a semi-transparent LED panel with a 2.6 mm horizontal pixel pitch and a 5.2 mm vertical pitch. The asymmetric grid lets natural light through, turning a glazed surface into an active advertising medium without hiding what sits behind it.

At 4000 nits, it stays fully legible behind a sun-exposed shop window, while the semi-transparent grid preserves 50 to 70 % of the natural light inside the store.

The 2.6 mm horizontal pitch is the finest in the CRYSTAL range: it is the one that renders small type, price tags and technical descriptions correctly. Combined with 4000 nits, it is the reference configuration for dynamic pricing displays in a street-facing window.

Key specifications

Pixel pitch: H 2.6 mm / V 5.2 mm
Brightness: 4000 nits (High Brightness)
Panel size: 1000 x 1000 mm
Refresh rate: 3840 Hz
Maintenance: front and rear access
Chassis: high-density extruded aluminium
Application: Behind glass, indoor or sun-exposed shop window

Avec un pitch de 2.6 mm, CRYSTAL P2.6 / 5.2 - HB - Dalle LED Semi transparente couvre les distances de vision moyennes (3 à 8 m). Conçu pour un usage indoor, ce module combine 4000 nits et 3840 Hz, soit l'ensemble des paramètres attendus sur une installation B2B professionnelle.

• Auditoriums & salles de conférence
• Retail & galeries commerciales
• Événementiel & studios XR

• Effective transparency — 50 to 70 % of daylight preserved depending on viewing angle; validate on a mock-up.
• Brightness — 4000 nits read in full daylight; enable the ambient sensor so the panel dims at night.
• Viewing distance — optimal from 3 m.
• Mounting — stainless-steel cable suspension recommended over bonding; front and rear maintenance access is retained.
• Text legibility — the 2.6 mm front pitch is the finest in the range: the right choice for pricing and menu boards.
